The 74LS32 is a dual input OR gate housed in a quad
package. It encompasses four independent gates, each executing the logical OR
function. Termed as a Quad 2-Input OR Gate, each gate boasts two inputs. This
IC belongs to the 74XXYY IC series. With a broad working voltage range and
compatibility with CMOS, NMOS, and TTL, the 74LS32 interacts directly with
various systems. Its output consistently adheres to TTL standards, facilitating
seamless integration with other TTL devices and microcontrollers. The 74LS32
IC, characterized by its compact size and enhanced speed, establishes
reliability across diverse devices. Logic gates like the 74LS32 and flip-flops
assume a pivotal role in digital electronics.
Features:
· Dual Input OR Gate – Quad
Package
· Technology Family: LS
· Supply Voltage: 5 to 7V
· Input Voltage: 5 to 7V
· VCC (Min): 4.75V
· VCC (Max): 5.25V
· Number of Channels: 4
· Inputs per Channel: 2
· IOL (Max): 0.8mA
· IOH (Max): -16mA
· Input Type: TTL-Compatible
CMOS
· Output Type: Push-Pull
· Features: High Speed (TPD
10-50ns)
· Data Rate (Max): 28Mbps
· Rating: Catalog
· Operating Temperature
Range: 0°C to 70°C (SN7432, SN74LS32, and SN74S32)
· Operating Temperature
Range: -55°C to 125°C (SN5432, SN54LS32, and SN54S32)
· Available in a 14-pin SOIC
package
