433MHz Transmitter and Receiver Module, FS1000A
(0) 0 Reviews 0 Orders 0 Wish listed
UGX10,000.00
Quantity :
Total price :
  (Tax : )
Out of stock
The 433MHz RF link kit is consisted of transmitter and receiver, popularly used for remote control.

FS1000A (Transmitter Part) Features & Technical Specifications:

  • Transmitter Model: FS1000A
  • Transmitting Frequency: 433.92MHz
  • Operating Voltage: 3V to 12V
  • Transmitting Power: 10mW to 40mW 16dBm
  • Transmitting Range: 20 to 100 meters through walls & 500 meters max in open area
  • Data Transfer Rate: <10 Kilo Bytes Per Second (Range drops above 2400 bytes per second)
  • Modulation Type: OOK
  • Current Consumption: 20 to 28mA
  • Current Consumption in Standby: 0mA



XY-MK-5V (Receiver Part) Features & Technical Specifications:

  • Receiver Model: XY-MK-5V
  • Transmitting Frequency: 433.92MHz
  • Operating Voltage: 5V
  • Receiving Sensitivity: 105DB
  • Modulation Type: OOK
  • Current Consumption in Standby: 4mA
