● Coil and contacts:
1500VAC/min
● Contact and contacts:
1000VAC/min
● Insulation resistance:
>=100M (ohm)
● Mounting form: PCB
● Outline dimensions (mm):
19.0x 15.5 x 15.0
● Contact form: 1a, 1b, 1c
● Rated load: 10A 250VAC/28VDC,
10A 125VAC/28VDC, 10A 125VAC/28VDC
● Contact resistance: <=100m
(ohm)
● Electrical life: 100,000
● Mechanical life: 10,000,000
● Coil rated voltage: 5VDC
● Coil power: 0.45W
● Coil pick-up voltage:
<=75%
● Coil drop-out voltage:
>=10%
● Ambient
temperature: -25 degrees Celsius to +70 degrees Celsius
