Specifications:
· Nominal
voltage: 12 V
· Free-run
speed at (12 V): 280 RPM
· Free-run
current at (12 V): 0.07A
· Rated
speed at (12 V): 215 RPM
· Rated
current at (12 V): 0.3A
· Rated
load torque at 12 V: 0.4 kg.cm
· Stall
current at 12 V: 1.8 A
· Stall
torque at 12 V: 2 kg.cm
· Gear
ratio: 1:(21.3)
· Reductor
size: 19 mm
Wiring
· Red:
motor power + (exchange can control the motor forward and reverse)
· Black:
Coded power supply – negative (positive and negative poles cannot be wrongly
connected to 3.3-5V)
· Yellow:
signal feedback (11 signals per motor revolution)
· Green:
signal feedback (11 signals per motor revolution)
· Blue:
Code power supply + positive (positive and negative poles can not be wrongly
connected 3.3-5V)
· White:
motor power – (reverse can control the motor forward and reverse)
