This
sensor from AMS has 6 integrated visible light sensing channels for red,
orange, yellow, green, blue, and violet. These channels can be read via the I2C
bus as either raw 16-bit values or calibrated floating-point values. There is
also an on-board temperature sensor that can be used to read the
temperature of the chip, and a powerful LED flash to reflect light off objects
for better color detection.
The
6 channels on the AS7262 are realized by silicon interference filters at 450nm,
500nm, 550nm, 570nm, 600nm, and 650nm. This breakout uses the I2C interface on
the chip by default, but a UART interface that accepts AT commands is also
selectable.
AS7262
has two communication interfaces: I2C and serial. The default is the
I2C interface. To use the serial interface, it is necessary to put tin
on the UART SELECT jumper. For serial communication with the computer, use
the USB-to-Serial converter. The board has 2x 7 pins
for soldering the gold pin strap of 2.54 mm.
Specifications:
Package
Contents:
1 x Spectrometer Module
