2.8"
240x320 SPI TFT LCD Serial Port Module SD ILI9341 5V/3.3V 2.8 inch LED Display
Module 5110 Interface With Touch Panel
Specifications:
· Display color RGB 65K color With
touch panel:
· Type: TFT
· Driver chip: ILI9341
· Resolution: 320*240 (Pixel)
· Module interface: 4-wire SPI interface
· Effective display area (AA
area): 43.2x57.6(mm)
· Module PCB backplane size: 50.0x86.0 (mm)
· Working temperature: -20℃~60℃
· Storage temperature: -30℃~70℃
· VCC power supply voltage: 3.3V~5V
· Logic IO port voltage: 3.3V (TTL)
Resources:
1. Interfacing Arduino with
ILI9341 color TFT display
2. Interfacing ESP8266 NodeMCU
with ILI9341 TFT display
3. Arduino TFT LCD Touch Screen Tutorial (2.8" ILI9341 Driver)
also for ESP32 (Youtube Video)
4. UNO R3 2.8 TFT Touch Screen
With SD Card Socket for Arduino Board Module
