The SIM7000G is a low-power cellular/NB-IoT/GNSS module commonly used for IoT, tracking, and remote monitoring projects SIMCom SIM7000G Module is a LPWA module which supports wireless communication modes of Cat-M/NB-IoT/GSM. SIMCom SIM7000G has powerful expansibility with abundant interfaces including UART, GPIO, PCM, I2C etc. it is designed for applications that need low latency, low throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, SIMCom SIM7000E Module is ideally suited for M2M applications, such as metering, asset tracking, remote monitoring, E-health and so on.

Specifications:

·         Operating Voltage: 5V (NOTE: The module will consume great amount of current immediately when connected to the network. So the external power supply is needed at work.)

·         Input Voltage: 7~12VDC (VIN range: 6~20V)

·         Communication Module: SIM7000

·         Single-Band TDD-LTE B39

·         Quad-Band FDD-LTE B1/B3/B5/B8 (SIM7000C)

·         Quad-Band FDD-LTE B3/B8/B20/B28 (SIM7000E)

·         GPRS/EDGE 900/1800 MHz

·         Output Power:

·         GSM900: 2W

·         DCS1800: 1W

v  Control Via AT Commands

v  Operation temperature: -40℃ to +85℃

v  GNSS (GPS, GLONASS, BeiDou, Compass, Galileo, QZSS)

v  Firmware update via USB 2.0

v  Support SIM card and NB-IoT card (NOTE: Please ensure the SIM frequency range been used is included in the frequency range it supports).

v  BME280 Environmental Sensor

·         Temperature Measuring Range: -40℃~+85℃, resolution of 0.1℃, deviation of ±0.5℃

·         Humidity Measuring Range: 0~100%RH, resolution of 0.1%RH, deviation of ±2%RH

·         Pressure Measuring Range: 300~1100hPa

·         Humidity Sampling Time: 1s

·         Operating Temperature：-30℃~+85℃

Network Technologies Supported

The SIM7000G supports multiple low-power and LTE categories:

• NB-IoT (NB1)
• LTE Cat-M1 (LTE-M)
• EGPRS (2G fallback) in some regions (depending on module version)

Resources:

1. SIM7000 Series_ AT Command Manual

2. LTE CAT-M/NB-IoT + GPS Shield for Arduino

3. SIM7000X NB-IoT HAT - more resources (WIKI)

 Note: For 4G applications, look for SIM7600G-H
