The LM2596 regulator is monolithic
integrated circuit ideally suited for easy and convenient design of a step−down
switching regulator (buck converter). It is capable of driving a 3.0 A load
with excellent line and load regulation. This device is available in adjustable
output version and it is internally compensated to minimize the number of
external components to simplify the power supply design.
Specifications:
|
Input Voltage |
3 to 40 V |
|
Output Voltage Range |
1.23 to 37 V |
|
Max Output Current |
3 A |
|
Adjustment |
25-Turn Trimpot |
|
Efficiency |
up to ~93% |
|
Switching Frequency |
150 kHz |
|
Built-In Protection |
thermal shutdown and current limit |
|
Dimensions: |
|
|
Length |
43.2 mm (1.701") |
|
Width |
21 mm (0.827") |
|
Height |
14 mm (0.551") |
|
Weight |
11.23 g (0.396 oz) |
